The C-Arm 3.5kW FPD DOXA Series DR is an advanced digital imaging system designed for orthopedic surgery, pain management, trauma care, and diagnostic procedures. Equipped with a 3.5kW high-frequency generator and DOXA Series DR Flat Panel Detector (FPD), it delivers high-resolution X-ray imaging, low radiation exposure, and real-time image acquisition. Its compact design, smooth mobility, and precise positioning ensure efficient workflow and accurate clinical outcomes in modern hospitals, surgical centers, and diagnostic facilities.
Advance Imaging with C-Arm 3.5kW FPD Doxa Series DR
Specification:
- 3.5kW High-Frequency X-Ray Generator
- DOXA Series DR Flat Panel Detector (FPD)
- High-Resolution Digital Imaging
Product Details:
Model
Advance Imaging with C-Arm 3.5kW FPD Doxa Series DR
Generator Power
3.5kW High-Frequency Generator
Detector Type
DOXA Series DR Flat Panel Detector (FPD)
Imaging Technology
Digital Radiography (DR)
Detector Material
Amorphous Silicon TFT/Diode Array
Scintillator
Direct-Deposit CsI:Tl
Active Imaging Area
236.5 × 236.5 mm
Pixel Pitch
154 μm
Pixel Matrix
1536 × 1536
Display System
Digital (kVp / mA / mAs / Time)
Image Acquisition
Real-Time Digital Imaging
C-Arm Movement
Smooth & Ergonomic Positioning
Radiation Exposure
Low Dose Technology
Clinical Applications
Orthopedics, Pain Management, Trauma Care & General Surgery
Connectivity
Gigabit Ethernet
X-Ray Interface
Integrated X-Ray Trigger Control
Housing Material
Anodized Aluminum Alloy
Protection Rating
IP30
Weight
Approx. 3.2 Kg
System Features
High Resolution Imaging, Fast Workflow & Precise Diagnostics
